产品样本
型号描述
直动式摇臂电磁阀 6606（二位二通和二位三通）满足分析技术领域的最高要求。它们具有最小的死角体积和一个无间隙、易于冲洗的内部轮廓。介质只能与外壳材料和 FFKM 密封件相接触。注入到介质中的热量控制在最少，因为已通过一块不锈钢板将外壳与线圈分离。阀门主要用于分析、医药和试验室技术领域中少量介质的计量、灌注、混合和分配。
1）满足严苛的耐化学腐蚀性要求
2）紧凑型结构，排列间距 16 mm，压力损失系数和流量系数 (Cv) 至 0.058
3）针对客户特殊应用的灵活设计
4）很高的反压力密封性，卓越的冲洗特性和 100 % 的接通时长
5）切断电源、打开电源或通用规格
Type Description
The direct-acting rocker solenoid valves with isolating diaphragm of Type 6606 (2/2- and 3/2–way) are high quality valves for analytical technology. They have minimal dead volume and internal volume with few crevices making them easy to flush out. The fluid only comes into contact with the body material and the FFKM seal. The heat transfer to the medium is minimal. The fluid path is isolated from the coil by a stainless steel plate. The valves are ideal for dosing, filling, mixing and distributing of small quantities of fluid for medical, analytical and laboratory applications.
1）For maximum chemical resistance requirements
2）Compact design with 16 mm width and Cv ratings up to 0.058
3）Flexible design for custom manifold assemblies
4）High back pressure tightness, excellent cleanability and 100 % duty cycle
5）Normally closed, normally open and universal function
6606型电磁阀部分订货号如下：
137741 6606-A01,6CCPKFB03-0-024/DC-AS * JB02
137742 6606-B01,6CCPKFB03-0-024/DC-AS * JB02
137743 6606-A01,6CCPKFB03-0-012/DC-AS * JB02
137744 6606-A01,6CCPKFB03-0-012/DC-AS * JC09+JW04
137745 6606-A01,6CCPKFB03-0-024/DC-AS * JC09+JW04
137746 6606-A01,6CCPDGM81-0-024/DC-AS * JB02
137747 6606-B01,6CCPDGM81-0-024/DC-AS * JB02
137748 6606-A01,6CCPDGM81-0-BCY/UC-04 * CZ24+JB04
137749 6606-A01,6CCPDGM81-0-024/DC-AS * JC09+JW04
137753 6606-A01,6CCPDNM81-0-012/DC-AS * JC09+JW04
137754 6606-A01,6CCPDNM81-0-024/DC-AS * JC09+JW04
137755 6606-A01,5CCTZUNFB-0-024/DC-AS * JB02
137758 6606-A01,5CCTZUNFB-0-012/DC-AS * JC09+JW04
137759 6606-A01,5CCTZUNFB-0-024/DC-AS * JC09+JW04
137760 6606-A01,6CCPDDA20-0-024/DC-AS * JB02
137762 6606-A01,6CCPDDA20-0-012/DC-AS * JB02
137763 6606-A01,6CCPDDA20-0-012/DC-AS * JC09+JW04
137764 6606-A01,6CCPDDA20-0-024/DC-AS * JC09+JW04
137765 6606-T01,6CCPKFB03-0-024/DC-AS * JB02
137766 6606-T01,6CCPKFB03-0-012/DC-AS * JB02
137767 6606-T01,6CCPKFB03-0-012/DC-AS * JC09+JW04
137768 6606-T01,6CCPKFB03-0-024/DC-AS * JC09+JW04
137769 6606-T01,6CCPDGM81-0-024/DC-AS * JB02
137770 6606-T01,6CCPDGM81-0-BCY/UC-04 * CZ24+JB04
137771 6606-T01,6CCPDGM81-0-024/DC-AS * JC09+JW04
137775 6606-T01,6CCPDNM81-0-024/DC-AS * JC09+JW04
137776 6606-T01,5CCTZUNFB-0-024/DC-AS * JB02
137778 6606-T01,5CCTZUNFB-0-012/DC-AS * JC09+JW04
137779 6606-T01,5CCTZUNFB-0-024/DC-AS * JC09+JW04
137780 6606-T01,6CCPDDA20-0-024/DC-AS * JB02
137781 6606-T01,6CCPDDA20-0-012/DC-AS * JB02
137782 6606-T01,6CCPDDA20-0-012/DC-AS * JC09+JW04
137783 6606-T01,6CCPDDA20-0-024/DC-AS * JC09+JW04
139145 6606-A01,6CCPKFB03-0-024/DC-AS * JF80
139146 6606-A01,6CCPDGM81-0-024/DC-AS * JF80
139147 6606-A01,6CCPDDA20-0-024/DC-AS * JF80
139148 6606-T01,6CCPKFB03-0-024/DC-AS * JF80
139149 6606-T01,6CCPDGM81-0-024/DC-AS * JF80
139150 6606-T01,6CCPDDA20-0-024/DC-AS * JF80
142863 6606-A01,5CCTZUNFB-0-024/DC-AS * JF80
142864 6606-T01,5CCTZUNFB-0-024/DC-AS * JF80
143743 6606-A01,2CCPKFB03-0-024/DC-AS * JF80+KR50
147487 6606-A01,6CCPDGM81-0-012/DC-AS * JB02+MA46
147938 6606-B01,6CCPKFB03-0-024/DC-AS * JC09+JW04
148184 6606-T01,6CFPDFB03-0-024/DC-AS * AC23+JC09+JW04
149047 6606-A00,0CC000000-0-024/UC-AS * CZ21+JF80+KA31+NA25+PC26
149435 6606-T01,2CAPKFB03-0-024/DC-AS * JF80+KR50
149498 6606-A01,6CAPKFB03-0-024/DC-AS * JF80
154747 6606-T01,6CCPKFB03-0-024/DC-AS * JB04
155293 6606-A01,6CCPKFB03-0-012/DC-AS * JF80
155471 6606-T01,6CCPDGM81-0-012/DC-AS * JB02
157741 6606-T01,5CCTZUNFB-0-024/DC-AS * JB04
157742 6606-A01,5CCTZUNFB-0-024/DC-AS * JB04
158086 6606-T01,6CCPDGM81-0-012/DC-AS * JC09+JW04
158658 6606-T01,2CCPKFB03-0-024/DC-AS * JC09+JW04
160632 6606-T00,8AAPKFB03-0-024/DC-AS * JB02+NB07
165844 6606-T01,6CCPDFB03-0-012/DC-AS * AC23+JC09+JW04
166467 6606-A01,6CCPDNM81-0-024/DC-AS * JF80
167180 6606-T00,8AAPKFB03-0-BCY/UC-04 * CZ24+JB04+NB07
167268 6606-T00,8FFPKFB03-0-012/DC-AS * JC09+JW04+KA31+MP08+NB07
168045 6606-T01,5CCTZUNFB-0-024/DC-AS * JF80+MA46
168163 6606-T01,6CCPSFB03-0-024/DC-AS * JB04+NB07
168480 6606-A01,6CCPKFB03-0-012/DC-AS * JC09+JW04+KA36
168525 6606-T01,5CCPFUNFB-0-024/DC-AS * JB04
168871 6606-T01,6CCPGUNFB-0-024/UC-AS * CZ21+JF80
169073 6606-A01,6FFPKFB03-0-024/DC-AS * JB04
169352 SYST-6606-2X137745-651506-ARMEN I.
169469 6606-T00,8FFPKFB03-0-BCY/UC-04 * CZ24+JB04+NB07
169488 6606-T01,6CCPKFB03-0-012/DC-AS * JF80
169782 6606-T01,6CCPKFB03-0-230/UC-04 * CZ24+JB04
170339 SYST-6606-4X137745-667032-ARMEN I. * JC09+JW04
170724 SYST-6606-2X137745-651578-ARMEN I. * JC09+JW04
171421 6606-T01,6AAPKFB03-0-024/DC-AS * JB02+NB07
172200 6606-T01,6AAPKFB03-0-024/DC-AS * JB04+NB07
180517 6606-T01,2AAPKDA20-0-024/DC-AS * JF80+KR50+NB03+NB07
180590 6606-T01,6CCPDGM81-0-024/UC-AS * CZ21+JF80
180634 6606-A01,2AAPKDA20-0-024/DC-AS * JF80+KR50+NB03+NB07
181357 6606-B01,5CCTZUNFB-0-024/DC-AS * JC09+JW25
197747 MICR-6606-SG-0197747-6606GRIFO
198761 MICR-6606-SG-0198761-PET-SYSTEMS
203205 6606-A01,6CCPDGM81-0-012/DC-AS * JC09+JW04
458094 6606-A01,6CCPDNM81-0-024/DC-AS * JF80+PD19
458096 6606-A01,6CCPDNM81-0-024/DC-AS * JC09+JW04+PD19
458098 6606-B01,5CCTZUNFB-0-024/DC-AS * JB02+PD19
458100 6606-A01,5CCTZUNFB-0-024/DC-AS * JF80+PD19
458103 6606-T01,6CCPDNM81-0-024/DC-AS * JB02+PD19
458106 6606-T01,6CCPDNM81-0-012/DC-AS * JC09+JW04+PD19
458108 6606-T01,5CCTZUNFB-0-024/DC-AS * JB02+PD19
458111 6606-T01,5CCTZUNFB-0-012/DC-AS * JC09+JW04+PD19
461632 6606-A01,6CCPDDA20-0-024/DC-AS * JF80+MA46+PD02
462814 6606-A01,6CCPDNM81-0-012/DC-AS * JC09+JW04+PD01
598076 SERV-6606-MATE-35-00020247-00166726
670649 KOMP-712-6606-G670-649-00-00670649
