burkert0121耐腐蚀两位两通电磁阀性能介绍

burkert0121型电磁阀说明：

直动式电磁阀，带转动衔铁原理，带手动开关。带隔离膜片直动式。具有多种回路功能，保证了对腐蚀性介质的密封隔离。

内孔：DN4.0-8.0MM

压力范围：0-2bar.max

阀体材质：PP或PVDF

密封材质： FFKM\FPM

FPM密封：氧化酸和氧化物、油类、盐溶液、废气

FFKM密封：中性和腐蚀性气体和液体

介质温度：

PVC+FKM密封：-10 to +50℃

PTFE/SS+FPM密封：-10 to +90 ℃

环境温度：Max.+55 ℃

Type Description

The 0121 valve is a direct-acting, media-separated pivoted armature valve. It is available in 3/2- and 2/2-way versions. As a 3/2-way version, it can be used as a distributor or mixing valve. Various diaphragm material combinations and methods of operation are available depending on the application. The housing offering includes stainless steel (316L), PTFE, and PVC versions. The solenoid coils are moulded with a chemically resistant epoxy. The 0121 is equipped with manual override for commissioning and testing. For reduced energy requirements, all coils can be delivered with electronic power reduction or as an impulse version. The switching status can be indicated with position feedback as a binary or NAMUR signal. In combination with a plug in accordance with DIN EN 17301-803 Form A, the valves satisfy protection class IP65/67 – in combination with a stainless steel or plastic housing NEMA 4X.

Direct-acting, media-separated valve with diameter of up to DN 8
Maintenance-free pivoted armature technology
Vibration-proof, block screwed coil system
Suitable for aggressive alkaline and acidic solutions
Service-friendly, durable manual override
